Detailed Product Description
| Type: | Filling Machine | Application: | Food, Honey Filling And Capping Machine |
|---|---|---|---|
| Automatic Grade: | Automatic | Dimension(L*W*H): | 2500x1500x1800mm |
| Language: | English/Chinese | Operate Panel: | Color Touch Screen |
| High Light: | capping machine for bottles, bottling capping machine | ||
Glass Bottle Honey Filling Machine , Honey Jar Filling And Capping Machine
Application
Machine is suitable for filling and capping semi-liquid products without or with small particles: such as sweet chili sauce, beef paste, bean sauce, mushroom sauce, tomato sauce, peanut butter, jam, honey, sauce, shrimp paste, shampoo, body wash, liquid detergent, dishwashing liquid, etc.
Technical Parameters
| Model | NP-JG4 |
| Filling nozzle number | 4 |
| Capping head | 1 |
| Filling volume | 50-1000ml |
| Production capacity | 10-40 bottles/min |
| Filling accuracy | ≤±1% |
| Capping rate | ≥98% |
| Air supply | 1.5m3/h 0.4-0.7 Mpa |
| Voltage | 220V, 50Hz |
| Power supply | 1.9KW |
| Machine net weight | 700kg |
| Machine dimension | 2500x1500x1800mm |
Machine function and features
1. This machine is suitable for honey, sauce, ketchup, jam, oil filling and capping.;
2. This machine adopts stainless piston measuring pump for filling, pneumatic capping, and rising-and-falling screwing;
3. Has advantages of accurate measurement, stable screwing and easy operation;
4. It is widely used in pharmaceuticals and cosmetic industries.
5. Meets requirements of GMP.
6. This machine can equip with other machines, such as labeling machine, printer, etc.
Tag: capping machine for bottles, bottling capping machine
